CDS^® Wrist Brace Extension

To provide wrist extension assist

Indications

Joint contractures

– After surgery
– After conservative treatment of capsular ligament injuries
– Before and after joint replacement
– In arthrosis and chronic polyarthritis
– After burns
– After stroke
– After spinal cord injuries
– Paralysis
– After cranio-cerebral trauma (CCT)

To prevent new contractures after arthrolysis

Features

Individual adjustment of the spring tension
Spring tension can be switched on and off without tools and without varying the set spring tension
Correction range can be adkusted in 15° intervals
Angle adjustable according to course of treatment
Individual adjustment of shells in position and shape
High wearing comfort due to air-permeable, light-weight aluminium shells
Precise adjustment of wrist to metacarpo-phalangeal (MCP) joint distance
Precise adjustment of MCP joint position
Adjustable hand resting plate

Mode of operation

The CDS^® Wrist Brace Extension can be used to treat an extension deficit of the wrist.
The dynamic stretch stimulates the healthy growth of the shortened tissue.
The continuously adjustable correction range prevents harmful over stretching.

Download CDS Brochure

CDS WRIST EXTENSION
FITTING INSTRUCTIONS FOR CLINICIANS
Access restricted to registered Clinicians
You'll need to click here then log in to activate

Size chart and product codes

Size	Junior (SS)	Adolescent (MM)	Adult Small (LS)	Adult Medium (LM)	Adult Large (LL)
Length of forearm shell medial	16 - 19 cm	17 - 19 cm	21 - 23.5 cm	21 - 23.5 cm	21 - 23.5 cm
Circumference of forearm	14 - 19 cm	18 - 24 cm	14 - 19 cm	18 - 24 cm	22 - 30 cm
Circumference of wrist	12 - 22 cm	16 - 26 cm	12 - 22 cm	16 - 26 cm	20 - 30 cm
Width of palm	6 cm	8 cm	6 cm	8 cm	10 cm
Code-left	931SS-L	931MM-L	931LS-L	931LM-L	931LL-L
Code-right	931SS-R	931MM-R	931LS-R	931LM-R	931LL-R
